Stainless Steel Springs for 3/4" SRVs | 4468

Write a Review
SKU -
4468
$14.87
$14.87

Description

Replacement 17-7 stainless-steel spring for Conrader brass-body hard-seat safety relief valves used on compressed-air, gas and elevated-temperature pressure-vessel service — dimensioned to the Conrader hard-seat valve body and supplied unset for shop-bench adjustment. Custom pressure set-points can be supplied to order; the assembled valve can be recertified and supplied with a batch certificate by the Ultramax Systems team. Held in Australian stock as an unset service-replacement spring, with recertification of the assembled valve supported by the Ultramax Systems team.

Features

  • Service-replacement part used during recertification of Conrader SRH hard-seat valves
  • Supplied unset for technician set-pressure adjustment on the test bench
  • 17-7 stainless-steel spring construction for consistent set-pressure over service life
  • Dimensioned to the Conrader SRH brass hard-seat valve body — installs in the genuine housing without modification
  • Stocked in Australia for fast turnaround on shop-bench work

Applications

  • Replacement spring for safety relief valves on compressed-air receivers and pressure vessels
  • Re-rating a safety relief valve to a different set pressure
  • Servicing and recertification of safety relief valves
  • Maintenance of compressor and pneumatic system relief valves
  • General industrial and workshop valve servicing

Specifications

Width
6.000 (cm)
Height
1.500 (cm)
Depth
1.500 (cm)
Cap Material
ASTM B16 Brass
Spring Material
17-7 Stainless Steel
Piston Material
ASTM B16 Brass
Seal Material
Silicone (Standard) / Viton (on Request)
Seat Material
ASTM B16 Brass
Colour
White
Pressure (psi)
126 - 170
SCFM
513 - 675
Flow Rate (scfm)
513 - 675
Notes
We can supply other pressure settings to order. All safety Valves can be recertified. Silicon Seal Max Temperature 120º C. Viton Seal Max Temperature 230º C
Pressure (kPa)
869 - 1172
