Description
The AB20X covers the ABAC PMH 2020 range in the Ultramax Systems alternative line. The element is a Grade X general purpose coalescing element, and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. The element belongs as the first coalescing stage, ahead of a dryer or a carbon tower. Taking that load out early keeps the finer stage behind it working to its rated life. Dimensions follow the original, so it installs into the existing housing without modification. FG/FS6 housings accept this element. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, ABAC F Series from 2020-compatible alternative. Designed as an alternative to OEM part numbers 2258293606 2258294006. It is engineered to suit housing models FG/FS6 PMHG119 PMHS119 FG20 FS20 FS 20 Size 6 FG 20 Size 6 FG / FS 20. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- FG/FS6
- PMHG119
- PMHS119
- FG20
- FS20
- FS 20 Size 6
- FG 20 Size 6
- FG / FS 20
- FG / FS 20 Size 6
- FS20 Size 6
- FG20 Size 6
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | AB20XYou are here | General Purpose Coalescer | 1 µm |
| A | AB20A | Activated Carbon | 0.01 µm |
| P | AB20P | General Purpose Coalescer | 3 µm |
| Y | AB20Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the ABAC PMH 2020 original, fits the existing housing without modification
- Suits FG/FS6 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Ring main protection
- Pre-filtration ahead of an activated carbon stage
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
