Description
The AF010Y covers the AFE Filter Elements range in the Ultramax Systems alternative line. The element is a Grade Y high efficiency oil removal coalescing element, and strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. In service it sits directly downstream of a Grade X stage. This is the stage that decides how much oil reaches the point of use. Dimensions follow the original, so it installs into the existing housing without modification. It is the element used in G0010H housings. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, AFE-compatible alternative. Designed as an alternative to OEM part numbers EA10H | ECQ10H | AF010F | AF010MX | AFEEA10H. It is engineered to suit housing models G0010H | G0010HI4 | G0010H14. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| AFE | EA10HECQ10HAF010FAF010MXAFEEA10HOAFEEA10H/S1010100101203 |
|---|
- G0010H
- G0010HI4
- G0010H14
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | AF010YYou are here | Oil Removal Coalescer | 0.01 µm |
| A | AF010A | Activated Carbon | 0.01 µm |
| P | AF010P | General Purpose Coalescer | 3 µm |
| X | AF010X | General Purpose Coalescer | 1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the AFE Filter Elements original, fits the existing housing without modification
- Suits G0010H and 2 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Air feeding pneumatic valves and actuators
- Pre-filtration ahead of an activated carbon stage
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
