Description
The AFR514X covers the AFE R Series range in the Ultramax Systems alternative line. It is a Grade X general purpose coalescing element and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. In service it sits as the first coalescing stage, ahead of a dryer or a carbon tower. Removing the bulk of the liquid here is what lets the downstream element do its job. The element is built to the original dimensions and needs no modification to the housing. It is the element used in R514U housings. Australian stock holding keeps lead times short, at a working budget price relative to the OEM part.
This replacement filter element from Ultramax is a high-quality, AFE R Series-compatible alternative. Designed as an alternative to OEM part numbers ERA514U-FAPE. It is engineered to suit housing models R514U. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- R514U
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | AFR514XYou are here | General Purpose Coalescer | 1 µm |
| A | AFR514A | Activated Carbon | 0.01 µm |
| P | AFR514P | General Purpose Coalescer | 3 µm |
| Y | AFR514Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the AFE R Series original, fits the existing housing without modification
- Suits R514U housings
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Spray and blow off applications
- Pre-filtration ahead of an activated carbon stage
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
