Description
The ALUP505X is the Ultramax Systems replacement element for the ALUP New range. As a Grade X general purpose coalescing element it removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. The element belongs as the first coalescing stage, ahead of a dryer or a carbon tower. Taking that load out early keeps the finer stage behind it working to its rated life. It matches the original on dimensional fit and drops into the existing housing without modification. G505 housings accept this element. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, ALUP-compatible alternative. Designed as an alternative to OEM part numbers 2258290117 | OALU 505 G/XM | 1.0101E+12. It is engineered to suit housing models G505 | S505. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| ALUP | 2258290117OALU 505 G/XM1.0101E+12 |
|---|
- G505
- S505
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | ALUP505XYou are here | General Purpose Coalescer | 1 µm |
| A | ALUP505A | Activated Carbon | 0.01 µm |
| P | ALUP505P | General Purpose Coalescer | 5 µm |
| Y | ALUP505Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the ALUP New original, fits the existing housing without modification
- Suits G505 and 1 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Ring main protection
- General workshop and plant air
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
