Description
The ATS515X is the Ultramax Systems replacement element for the ATS BGX 2022 range. The element is a Grade X general purpose coalescing element, and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. The element belongs as the first coalescing stage, ahead of a dryer or a carbon tower. Removing the bulk of the liquid here is what lets the downstream element do its job. The element is built to the original dimensions and needs no modification to the housing. It is the element used in BG-0515A housings. It is held in Australian stock and priced to work against the cost of going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, ATS-compatible alternative. Designed as an alternative to OEM part numbers BGX-515A. It is engineered to suit housing models BG-0515A. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- BG-0515A
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | ATS515XYou are here | General Purpose Coalescer | 1 µm |
| A | ATS515A | Activated Carbon | 0.01 µm |
| P | ATS515P | General Purpose Coalescer | 3 µm |
| Y | ATS515Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the ATS BGX 2022 original, fits the existing housing without modification
- Suits BG-0515A housings
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Compressor room outlet filtration
- General workshop and plant air
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
