Description
Within the Bottarini Elements range, the BO22075X is the Ultramax Systems replacement element. It is a Grade X general purpose coalescing element and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. The element belongs as the first coalescing stage, ahead of a dryer or a carbon tower. Clearing this load first protects the dryer or carbon stage that follows. Dimensions follow the original, so it installs into the existing housing without modification. F030M housings accept this element. It is held in Australian stock and priced to work against the cost of going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Bottarini-compatible alternative. Designed as an alternative to OEM part numbers 223185 EBT030U. It is engineered to suit housing models F030M. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- F030M
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | BO22075XYou are here | General Purpose Coalescer | 1 µm |
| A | BO22075A | Activated Carbon | 0.01 µm |
| P | BO22075P | General Purpose Coalescer | 5 µm |
| Y | BO22075Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the Bottarini Elements original, fits the existing housing without modification
- Suits F030M housings
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Compressor room outlet filtration
- Air feeding automated production equipment
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
