Description
Within the Ceccato F PMH Series range, the CEC4X is the Ultramax Systems replacement element. The element is a Grade X general purpose coalescing element, and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. In service it sits as the first coalescing stage, ahead of a dryer or a carbon tower. Clearing this load first protects the dryer or carbon stage that follows. The element is built to the original dimensions and needs no modification to the housing. FG/FS2 housings accept this element. Australian stock holding keeps lead times short, at a working budget price relative to the OEM part.
This replacement filter element from Ultramax is a high-quality, Ceccato F Series from 2020-compatible alternative. Designed as an alternative to OEM part numbers 2258293602 2258 293 602 OCE F2 G-S/XM 1010100109506. It is engineered to suit housing models FG/FS2 FG2 - FS2 GS2 G/S 2 GS 2 2 G/S 2 GS FG4. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- FG/FS2
- FG2 - FS2
- GS2
- G/S 2
- GS 2
- 2 G/S
- 2 GS
- FG4
- FS4
- FG / FS 2
- FG 4
- FS 4
- FG - FS 2
- FG-FS2
- FG2-FS2
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | CEC4XYou are here | General Purpose Coalescer | 1 µm |
| A | CEC4A | Activated Carbon | 0.01 µm |
| P | CEC4P | General Purpose Coalescer | 3 µm |
| Y | CEC4Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the Ceccato F PMH Series original, fits the existing housing without modification
- Suits FG/FS2 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Air feeding automated production equipment
- Pre-filtration ahead of an activated carbon stage
