Description
Within the Omega AAF range, the CEF5528A is the Ultramax Systems replacement element. The element is a Grade A activated carbon element, and adsorbs the oil vapour and hydrocarbon odour that liquid coalescers cannot hold, rated at 0.01 µm. It sits as the final stage before air reaches product, packaging or people. This is the last stage before the air touches anything that matters. Dimensions follow the original, so it installs into the existing housing without modification. It is the element used in AAF 0016A housings. Australian stock holding keeps lead times short, at a working budget price relative to the OEM part.
This replacement filter element from Ultramax is a high-quality, Omega AAF-compatible alternative. Designed as an alternative to OEM part numbers 05528A AAF 05528A 05528XA. It is engineered to suit housing models AAF 0016A AAF0016A AAF0016XA. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- AAF 0016A
- AAF0016A
- AAF0016XA
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| A | CEF5528AYou are here | Activated Carbon | 0.01 µm |
| P | CEF5528P | General Purpose Coalescer | 3 µm |
| X | CEF5528X | General Purpose Coalescer | 1 µm |
| Y | CEF5528Y | Oil Removal Coalescer | 0.01 µm |
| YO | CEF5528YO | Oil Removal Coalescer | 0.1 µm |
Features
- Grade A media rated at 0.01 µm
- Adsorbs the oil vapour and hydrocarbon odour that liquid coalescers cannot hold
- Dimensional match to the Omega AAF original, fits the existing housing without modification
- Suits AAF 0016A and 2 further housing models
- Held in Australian stock, not brought in to order
Applications
- Food and beverage processing
- Packaging lines
- Dairy and beverage filling
- Breathing air systems
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
