Description
The CF082X covers the CompAir CF 2424 IR range in the Ultramax Systems alternative line. It is a Grade X general purpose coalescing element and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. In service it sits as the first coalescing stage, ahead of a dryer or a carbon tower. Taking that load out early keeps the finer stage behind it working to its rated life. Dimensions follow the original, so it installs into the existing housing without modification. Housings in the CE082L11/2E family take this element. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, CompAir CF Series from 2020-compatible alternative. Designed as an alternative to OEM part numbers CFE082E 47699054001 CE082E OCO CF082 E/XR 1010100110833. It is engineered to suit housing models CE082L11/2E CF082L1 1/2"E CF082L1 1/2"E 47698784001 CF082E CF082L1 1/2"E CE082L1 1/2"E. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- CE082L11/2E
- CF082L1 1/2"E
- 47698784001
- CF082E
- CE082L1 1/2"E
- CF082L1_1/2"E
- CE082L1 1_2"E
- CF082L1 1/2″E
- CE082L1 1/2″E
- CF082L1_1/2″E
- CE082L1 1_2″E
- CE082L 1 1/2″E
- CF082L 1_1/2″E
- CE082L 1 1_2″E
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | CF082XYou are here | General Purpose Coalescer | 1 µm |
| A | CF082A | Activated Carbon | 0.01 µm |
| XO | CF082XO | General Purpose Coalescer | 0.1 µm |
| Y | CF082Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the CompAir CF 2424 IR original, fits the existing housing without modification
- Suits CE082L11/2E and 3 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Spray and blow off applications
- Compressor room outlet filtration
