Description
Within the Chicago Pneumatic New range, the CH1890Y is the Ultramax Systems replacement element. As a Grade Y high efficiency oil removal coalescing element it strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. It sits directly downstream of a Grade X stage. Air leaving this stage is clean enough for instrument work and for a carbon tower to polish. The element is built to the original dimensions and needs no modification to the housing. It is the element used in C1890 housings. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, Chicago Pneumatic New-compatible alternative. Designed as an alternative to OEM part numbers 2258290132 | 2258293210 | 8102853168 | 8102826644 | CPC1110F. It is engineered to suit housing models C1890 | 12-C-D | 12-D-G | 12C/D | 12CD. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| Chicago Pneumatic New | 2258290132225829321081028531688102826644CPC1110FECPG1110HOCP 1890 C/XS1010100100539 |
|---|
- C1890
- 12-C-D
- 12-D-G
- 12C/D
- 12CD
- 12-C-G
- 12-C-G 3
- 12C/G
- 12CG
- C1110
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | CH1890YYou are here | Oil Removal Coalescer | 0.01 µm |
| Y | CH1890A | Oil Removal Coalescer | 0.01 µm |
| P | CH1890P | General Purpose Coalescer | 3 µm |
| X | CH1890X | General Purpose Coalescer | 1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Chicago Pneumatic New original, fits the existing housing without modification
- Suits C1890 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Printing and packaging equipment
- Laboratory and analytical air
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
