Description
The CHP76090Y covers the Chicago Pneumatic CP range in the Ultramax Systems alternative line. It is a Grade Y high efficiency oil removal coalescing element and strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. It sits directly downstream of a Grade X stage. Air leaving this stage is clean enough for instrument work and for a carbon tower to polish. Dimensions follow the original, so it installs into the existing housing without modification. It is the element used in CPFS1500 housings. It is held in Australian stock and priced to work against the cost of going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Chicago Pneumatic CP - Older-compatible alternative. Designed as an alternative to OEM part numbers 2258290033 ECP1500H OCP 1500 MBS/XS FMM0240F 1.0101E+12 2258 2900 33. It is engineered to suit housing models CPFS1500 CPFS 1500. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- CPFS1500
- CPFS 1500
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | CHP76090YYou are here | Oil Removal Coalescer | 0.01 µm |
| A | CHP76090A | Activated Carbon | 0.01 µm |
| P | CHP76090P | General Purpose Coalescer | 3 µm |
| X | CHP76090X | General Purpose Coalescer | 1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Chicago Pneumatic CP original, fits the existing housing without modification
- Suits CPFS1500 and 1 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Processes sensitive to oil carryover
- Electronics assembly and test
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
