Description
The CHPF10P covers the Chicago Pneumatic F series range in the Ultramax Systems alternative line. As a Grade P general purpose particulate element it holds bulk solid debris, pipe scale and rust, rated at 5 µm. The element belongs at the front of the train, protecting the finer stages behind it. Catching the coarse load here keeps the coalescing stages from blinding early. It matches the original on dimensional fit and drops into the existing housing without modification. It is the element used in FP10 housings. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, Chicago Pneumatic F Series from 2020-compatible alternative. Designed as an alternative to OEM part numbers 2258293501 2258 293 501 OCP F1 P/XR 1010100109601. It is engineered to suit housing models FP10 FP 10 (G1/8") - CP FP-1 FP-10 FP/10 FP - 10. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- FP10
- FP 10 (G1/8") - CP
- FP-1
- FP-10
- FP/10
- FP - 10
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| P | CHPF10PYou are here | General Purpose Coalescer | 5 µm |
| A | CHPF10A | Activated Carbon | 0.01 µm |
| X | CHPF10X | General Purpose Coalescer | 1 µm |
| Y | CHPF10Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade P media rated at 5 µm
- Holds bulk solid debris, pipe scale and rust
- Dimensional match to the Chicago Pneumatic F series original, fits the existing housing without modification
- Suits FP10 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- First stage protection on a new installation
- Air lines carrying pipe scale or rust
- Air receivers and ring mains
- Older reticulation systems
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
