Description
Within the Chicago Pneumatic F series range, the CHPF1529Y is the Ultramax Systems replacement element. It is a Grade Y high efficiency oil removal coalescing element and strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. The element belongs directly downstream of a Grade X stage. Air leaving this stage is clean enough for instrument work and for a carbon tower to polish. Dimensions follow the original, so it installs into the existing housing without modification. It is the element used in FC1529 housings. It is held in Australian stock and priced to work against the cost of going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Chicago Pneumatic F Series from 2020-compatible alternative. Designed as an alternative to OEM part numbers 2258293716 2258 293 716 OCP F16 C-D/XS 1010100109663. It is engineered to suit housing models FC1529 FD - 1529 FC 1529 (G3") - CP FD1529 FC/D-16 FC-1529 FD-1529 FC/1529. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- FC1529
- FD - 1529
- FC 1529 (G3") - CP
- FD1529
- FC/D-16
- FC-1529
- FD-1529
- FC/1529
- FD/1529
- FC - 1529
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | CHPF1529YYou are here | Oil Removal Coalescer | 0.01 µm |
| A | CHPF1529A | Activated Carbon | 0.01 µm |
| P | CHPF1529P | General Purpose Coalescer | 5 µm |
| X | CHPF1529X | General Purpose Coalescer | 1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Chicago Pneumatic F series original, fits the existing housing without modification
- Suits FC1529 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Electronics assembly and test
- Air feeding pneumatic valves and actuators
