Description
Within the Chicago Pneumatic F series range, the CHPF54Y is the Ultramax Systems replacement element. The element is a Grade Y high efficiency oil removal coalescing element, and strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. The element belongs directly downstream of a Grade X stage. This is the stage that decides how much oil reaches the point of use. It matches the original on dimensional fit and drops into the existing housing without modification. It is the element used in FC54 housings. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, Chicago Pneumatic F Series from 2020-compatible alternative. Designed as an alternative to OEM part numbers 2258293704 2258 293 704 OCP F4 C-D/XS 1010100109615. It is engineered to suit housing models FC54 FD - 54 FC 54 (G3/8") - CP FD54 FC/D-4 FC-54 FD-54 FC/54. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- FC54
- FD - 54
- FC 54 (G3/8") - CP
- FD54
- FC/D-4
- FC-54
- FD-54
- FC/54
- FD/54
- FC - 54
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | CHPF54YYou are here | Oil Removal Coalescer | 0.01 µm |
| A | CHPF54A | Activated Carbon | 0.01 µm |
| P | CHPF54P | General Purpose Coalescer | 5 µm |
| X | CHPF54X | General Purpose Coalescer | 1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Chicago Pneumatic F series original, fits the existing housing without modification
- Suits FC54 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Electronics assembly and test
- Laboratory and analytical air
