Description
The DOUF2030XO covers the Donaldson 90 Series range in the Ultramax Systems alternative line. It is a Grade XO general purpose coalescing element and removes oil aerosol, water and solid particulate from the air stream, rated at 0.1 µm. It sits as the first coalescing stage in the train. Taking that load out early keeps the finer stage behind it working to its rated life. Dimensions follow the original, so it installs into the existing housing without modification. It is the element used in AG0144MF housings. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Donaldson 90 Series-compatible alternative. Designed as an alternative to OEM part numbers MF20/30 | MF 20/30 | RMF20/30 | 20/30RMF | MF2030PG. It is engineered to suit housing models AG0144MF | AG0144 MF | AG0144-MF | AG 0144MF | AG 0144 MF. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| Donaldson 90 Series | MF20/30MF 20/30RMF20/3020/30RMFMF2030PG20/30 RMFODO2030MFODO2030 MF1C120380ODO 2030MFODO 2030 MFODO 2030 XMF MF 20/30 1010100103876 |
|---|---|
| Donaldson | MF 20/3 |
- AG0144MF
- AG0144 MF
- AG0144-MF
- AG 0144MF
- AG 0144 MF
- AG 0144-MF
- AG 0144
- AG 0144 2 1/2
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| XO | DOUF2030XOYou are here | General Purpose Coalescer | 0.1 µm |
| A | DOUF2030A | Activated Carbon | 0.01 µm |
| P | DOUF2030P | General Purpose Coalescer | 3 µm |
| X | DOUF2030X | General Purpose Coalescer | 1 µm |
| Y | DOUF2030Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade XO media rated at 0.1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the Donaldson 90 Series original, fits the existing housing without modification
- Suits AG0144MF and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Spray and blow off applications
- Ring main protection
