Description
Ultramax Systems supplies the OM0010X as a direct replacement within the OMI F Series range. It is a Grade X general purpose coalescing element and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. The element belongs as the first coalescing stage, ahead of a dryer or a carbon tower. Clearing this load first protects the dryer or carbon stage that follows. The element is built to the original dimensions and needs no modification to the housing. It is the element used in F0010PF housings. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, OMI F Series-compatible alternative. Designed as an alternative to OEM part numbers 04E0060PF | EOM0008U | APO04E0060HFP1 | OOM0008PF/M | 0MI0010P1. It is engineered to suit housing models F0010PF. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| OMI F Series | 04E0060PFEOM0008UAPO04E0060HFP1OOM0008PF/M0MI0010P1 |
|---|
- F0010PF
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | OM0010XYou are here | General Purpose Coalescer | 1 µm |
| A | OM0010A | Activated Carbon | 0.01 µm |
| P | OM0010P | General Purpose Coalescer | 5 µm |
| Y | OM0010Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the OMI F Series original, fits the existing housing without modification
- Suits F0010PF housings
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- General workshop and plant air
- Ring main protection
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
