Description
Within the Omega HF range, the OM32090PS is the Ultramax Systems replacement element. It is a Grade PS replacement filter element and holds the contamination its housing is placed to catch, rated at 15 µm. It sits in the position the original element occupied. Catching the coarse load here keeps the coalescing stages from blinding early. The element is built to the original dimensions and needs no modification to the housing. Housings in the HF 070 family take this element. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Omega HF-compatible alternative. Designed as an alternative to OEM part numbers 32090B. It is engineered to suit housing models HF 070. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- HF 070
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| PS | OM32090PSYou are here | 15 µm | |
| A | OM32090A | Activated Carbon | 0.01 µm |
| P | OM32090P | General Purpose Coalescer | 3 µm |
| X | OM32090X | General Purpose Coalescer | 1 µm |
| Y | OM32090Y | Oil Removal Coalescer | 0.01 µm |
| YO | OM32090YO | Oil Removal Coalescer | 0.1 µm |
Features
- Grade PS media rated at 15 µm
- Holds the contamination its housing is placed to catch
- Dimensional match to the Omega HF original, fits the existing housing without modification
- Suits HF 070 housings
- Held in Australian stock, not brought in to order
Applications
- First stage protection on a new installation
- Air lines carrying pipe scale or rust
- Compressor outlet protection
- Older reticulation systems
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
