Description
Within the Chicago Pneumatic F series range, the PMH42P is the Ultramax Systems replacement element. The element is a Grade P general purpose particulate element, and holds bulk solid debris, pipe scale and rust, rated at 3 µm. In service it sits at the front of the train, protecting the finer stages behind it. Catching the coarse load here keeps the coalescing stages from blinding early. Dimensions follow the original, so it installs into the existing housing without modification. Housings in the PMHP42 family take this element. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, Pneumatech PMH-compatible alternative. Designed as an alternative to OEM part numbers 2258293503 2258 293 503. It is engineered to suit housing models PMHP42 PMH P 42 PMH FP 42 (G1/4") - M PMH FP 42 (G1/4) - M PMH P42 PMH P 42 (G1/4") G A PMH P 42 (G1/4) G A 8102856322. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- PMHP42
- PMH P 42
- PMH FP 42 (G1/4") - M
- PMH FP 42 (G1/4) - M
- PMH P42
- PMH P 42 (G1/4") G A
- PMH P 42 (G1/4) G A
- 8102856322
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| P | PMH42PYou are here | General Purpose Coalescer | 3 µm |
| A | PMH42A | Activated Carbon | 0.01 µm |
| X | PMH42X | General Purpose Coalescer | 1 µm |
| Y | PMH42Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade P media rated at 3 µm
- Holds bulk solid debris, pipe scale and rust
- Dimensional match to the Chicago Pneumatic F series original, fits the existing housing without modification
- Suits PMHP42 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- First stage protection on a new installation
- Air lines carrying pipe scale or rust
- Older reticulation systems
- Air receivers and ring mains
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
