Description
The PNTC315Y is the Ultramax Systems replacement element for the Pneumatech TF range. It is a Grade Y high efficiency oil removal coalescing element and strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. The element belongs directly downstream of a Grade X stage. Air leaving this stage is clean enough for instrument work and for a carbon tower to polish. The element is built to the original dimensions and needs no modification to the housing. Housings in the C765 family take this element. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Pneumatech TF-compatible alternative. Designed as an alternative to OEM part numbers 2258290132. It is engineered to suit housing models C765 PF10CHE D765 PF10DHE. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- C765
- PF10CHE
- D765
- PF10DHE
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | PNTC315YYou are here | Oil Removal Coalescer | 0.01 µm |
| A | PNTC315A | Activated Carbon | 0.01 µm |
| P | PNTC315P | General Purpose Coalescer | 3 µm |
| X | PNTC315X | General Purpose Coalescer | 1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Pneumatech TF original, fits the existing housing without modification
- Suits C765 and 3 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Electronics assembly and test
- Air feeding pneumatic valves and actuators
