Description
The Nano S SEP 3500 ST oil water separator treats compressor condensate on systems up to 3,500 cfm (99 m3/min). A single high-capacity unit handles flows that would otherwise require multiple separator towers, polishing condensate for legal discharge to the foul drain with oil carry-over below 5 ppm at installation. The unit is supplied with outlet pipe, sealing ring, test kit and grab trap, plus a service interval indicator, weekly check sheet and instruction manual. A diffuser-equipped variant is available where inlet conditions require it. Weekly outlet checks are made with the supplied test kit. Media replacement is via the SEP-SK3500 service kit.
Features
- Single high-capacity unit and filter - treats large systems without multiple towers
- Supplied with outlet pipe, white sealing ring, test kit and grab trap
- Diffuser-equipped variant available
- Service interval indicator (Timestrip) included
- Inlet connections 2 x 3/4 in; outlet 1 x 1 in
Applications
- Oil-flooded compressor condensate treatment (mineral and synthetic lubricants)
- Compressed air and gas systems
- Compressor houses and plant rooms
- Condensate from receiver tanks, dryers and filter housings
