Description
The SPXPF14X is the Ultramax Systems replacement element for the SPX NGF range. It is a Grade X general purpose coalescing element and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. In service it sits as the first coalescing stage, ahead of a dryer or a carbon tower. Clearing this load first protects the dryer or carbon stage that follows. Dimensions follow the original, so it installs into the existing housing without modification. Housings in the F14-CF-T family take this element. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, SPX NGF-compatible alternative. Designed as an alternative to OEM part numbers PF-14. It is engineered to suit housing models F14-CF-T. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- F14-CF-T
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | SPXPF14XYou are here | General Purpose Coalescer | 1 µm |
| A | SPXCF14A | Activated Carbon | 0.01 µm |
| Y | SPXHF14Y | Oil Removal Coalescer | 0.01 µm |
| P | SPXSF14P | General Purpose Coalescer | 3 µm |
| YO | SPXUF14YO | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the SPX NGF original, fits the existing housing without modification
- Suits F14-CF-T housings
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Ring main protection
- Air feeding automated production equipment
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
