3/4" NPT - Hard Seat - ASME Coded - SRH 580 | SRH 3/4" NPT - 174/1200

Write a Review
SKU -
SRH 3/4" NPT - 174/1200
$408.02
$408.02

Description

This Conrader hard seat safety relief valve in 3/4" NPT provides dependable overpressure protection on compressed-air systems, receivers and pressure vessels — supplied by Ultramax Systems for Australian industrial installations. Factory-set to 174 psi (1200 kPa / 12.0 bar), rated flow of 688 scfm, with an astm b16 brass seat, ASME-coded for pressure-vessel and receiver service. Supplied from Australian stock with batch certification on request and full recertification supported by the Ultramax Systems technical team.

Features

  • AS-coded and ASME-coded variants available across the range
  • Brass body construction with metal-to-metal hard seat for demanding service
  • Suitable for compressed air, gas and steam service within rated temperature limits
  • Factory set, tested and tagged to the marked pressure setting
  • Metric and BSP threaded body configurations for compressor and pressure-vessel mounting

Applications

  • Air compressor receivers and air-line pressure vessels
  • Reciprocating and rotary compressor installations
  • Pressure vessels containing non-hazardous compressed gases
  • Compressed-air distribution networks and pneumatic equipment
  • General industrial and workshop air systems

Specifications

Width
9.000 (cm)
Height
4.000 (cm)
Depth
5.000 (cm)
Cap Material
ASTM B16 Brass
Spring Material
17-7 Stainless Steel
Piston Material
ASTM B16 Brass
Pressure (psi)
174
Seal Material
Silicone (Standard) / Viton (on Request)
Seat Material
ASTM B16 Brass
Temp. Range
-53°C to 205°C
Flow Rate (scfm)
688
Notes
We can supply other pressure settings to order. All safety Valves can be recertified. Silicon Seal Max Temperature 120º C. Viton Seal Max Temperature 230º C
Pressure (kPa)
1200
