Description
The Conrader SRV is a hard seat safety relief valve in M22x1.5, supplied by Ultramax Systems for overpressure protection on compressed-air receivers, pressure vessels and gas installations. Factory-set to 125 psi (861 kPa / 8.6 bar), rated flow of 506 scfm, with an astm b16 brass seat, AS-coded for Australian-Standards pressure-vessel service. Stocked in Australia by Ultramax Systems, with batch certificates and recertification available on request.
Features
- Robust internal trim for repeated pressure-relief cycles without sealing degradation
- Suitable for compressed air, gas and steam service within rated temperature limits
- AS-coded and ASME-coded variants available across the range
- Hard seat design suited to elevated temperatures and aggressive service media
- Brass body construction with metal-to-metal hard seat for demanding service
Applications
- Intercoolers and aftercoolers on compressed-air systems
- Reciprocating and rotary compressors in demanding service
- Pressure vessels operating at elevated temperatures
- Industrial gas distribution lines requiring metal-seat reliability
