Description
Conrader soft seat safety relief valves in 1-1/2" BSPP sit on compressor receivers and pressure vessels as the final safety stage against over-pressure events. This SKU is the 1-1/2" BSPP configuration. Factory-set to 150 psi (1034 kPa / 10.3 bar), rated flow of 2498 scfm, with an astm b16 brass seat, AS-coded for Australian-Standards pressure-vessel service. Australian-stocked, with batch certificates available on request and recertification handled in-house by Ultramax Systems.
Features
- Factory set, tested and tagged to the marked pressure setting
- Soft seat design provides leak-tight sealing and reliable reseating after relief
- Brass body construction for corrosion resistance in compressed-air and gas service
- Seal options for elevated-temperature service (silicon to 120°C, Viton to 230°C)
- Threaded body in standard BSP, BSPP and NPT configurations for direct fit on receivers
Applications
- Industrial nitrogen, CO2 and inert-gas systems
- Compressed-air distribution networks and pressure regulators
- Air compressor receivers and air-line pressure vessels
- Pressure vessels containing non-hazardous compressed gases
- Intercoolers and aftercoolers on reciprocating and rotary compressors
