Description
Conrader soft seat safety relief valves in 1/8" NPT sit on compressor receivers and pressure vessels as the final stage of overpressure protection. This SKU is covering an adjustable set range of 25 to 450 psi (172 to 3103 kPa), the NPT configuration. The brass body and soft seat deliver dependable sealing in compressed air and gas service and ASME coding. The rated flow is 31 - 377 scfm. Operating temperature range -53°C to 120°C. Australian-stocked by Ultramax Systems, with batch certificates available on request and recertification handled in-house.
Features
- NPT threaded connection for direct fit to receivers
- Spring-loaded with automatic reseating once pressure returns
- Suitable for compressed air, inert gas and non-aggressive media
- ASME coded for pressure-vessel and receiver duty
- Rated flow 31 - 377 scfm
- Brass body with soft seat for reliable sealing
Applications
- Air compressor receivers and air-line pressure vessels
- Reciprocating and rotary compressor installations
- Pressure vessels containing non-hazardous compressed gases
- Compressed-air distribution networks and pneumatic equipment
- General industrial and workshop air systems
