Description
Conrader soft seat safety relief valves in 2" NPT sit on compressor receivers and pressure vessels as the final safety stage against over-pressure events. This SKU is the 2" NPT configuration. Factory-set to 200 psi (1379 kPa / 13.8 bar), rated flow of 4897 scfm, with an astm b16 brass seat, AS-coded for Australian-Standards pressure-vessel service. Australian-stocked, with batch certificates available on request and recertification handled in-house by Ultramax Systems.
Features
- Stainless-steel spring for consistent set-pressure across the service interval
- Soft seat design provides leak-tight sealing and reliable reseating after relief
- Compact body footprint for mounting on small receivers and pressure vessels
- Brass body construction for corrosion resistance in compressed-air and gas service
- Seal options for elevated-temperature service (silicon to 120°C, Viton to 230°C)
Applications
- Pressure vessels containing non-hazardous compressed gases
- Compressed-air distribution networks and pressure regulators
- Bypass relief on regulated air and gas circuits
- Industrial nitrogen, CO2 and inert-gas systems
- Air compressor receivers and air-line pressure vessels
