Description
Ultramax Systems supplies the SW014X as a direct replacement within the Sunwin Series 2 Denair range. The element is a Grade X general purpose coalescing element, and removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. It sits as the first coalescing stage, ahead of a dryer or a carbon tower. Clearing this load first protects the dryer or carbon stage that follows. It matches the original on dimensional fit and drops into the existing housing without modification. It is the element used in AWT-001 housings. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, Sunwin S3-compatible alternative. Designed as an alternative to OEM part numbers E014-AO. It is engineered to suit housing models AWT-001 | AWT-001DG. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| Sunwin AW Series | E014-AO |
|---|
- AWT-001
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | SW014XYou are here | General Purpose Coalescer | 1 µm |
| A | SW014A | Activated Carbon | — |
| P | SW014P | General Purpose Coalescer | 3 µm |
| Y | SW014Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the Sunwin Series 2 Denair original, fits the existing housing without modification
- Suits AWT-001 and 1 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Compressor room outlet filtration
- General workshop and plant air
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
