Description
Within the Ultrafilter 80 new Sheet range, the UF310Y is the Ultramax Systems replacement element. As a Grade Y high efficiency oil removal coalescing element it strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. The element belongs directly downstream of a Grade X stage. Air leaving this stage is clean enough for instrument work and for a carbon tower to polish. Dimensions follow the original, so it installs into the existing housing without modification. AG 0005MVAK housings accept this element. Australian stock holding keeps lead times short, at a working budget price relative to the OEM part.
This replacement filter element from Ultramax is a high-quality, Ultrafilter 80 Series-compatible alternative. Designed as an alternative to OEM part numbers AK3/1 | EU3/1 | EU3/1D | EU3/1H. It is engineered to suit housing models AG 0005MVAK | AG 0005 MVAK | AG0005MVAK. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| Ultrafilter 80 Series | AK3/1EU3/1EU3/1DEU3/1H |
|---|
- AG 0005MVAK
- AG 0005 MVAK
- AG0005MVAK
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | UF310YYou are here | Oil Removal Coalescer | 0.01 µm |
| A | UF310A | Activated Carbon | 0.01 µm |
| A | UF310A-HT | Activated Carbon | 0.01 µm |
| P | UF310P | General Purpose Coalescer | 5 µm |
| P | UF310P-HT | General Purpose Coalescer | 3 µm |
| X | UF310X | General Purpose Coalescer | 1 µm |
| X | UF310X-HT | General Purpose Coalescer | 1 µm |
| XO | UF310XO | General Purpose Coalescer | 0.1 µm |
| XO | UF310XO-HT | General Purpose Coalescer | 0.1 µm |
| Y | UF310Y-HT | Oil Removal Coalescer | 0.01 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Ultrafilter 80 new Sheet original, fits the existing housing without modification
- Suits AG 0005MVAK and 2 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Processes sensitive to oil carryover
- Electronics assembly and test
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
