Description
Ultramax Systems supplies the UF530XO as a direct replacement within the Ultrafilter 80 new Sheet range. As a Grade XO general purpose coalescing element it removes oil aerosol, water and solid particulate from the air stream, rated at 0.1 µm. In service it sits as the first coalescing stage in the train. Clearing this load first protects the dryer or carbon stage that follows. It matches the original on dimensional fit and drops into the existing housing without modification. It is the element used in AG 0030MF housings. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Ultrafilter 80 Series-compatible alternative. Designed as an alternative to OEM part numbers MF5/3 SMF5/3 EU5/3H MF 05/3 SMF 05/3 ODO 053 XSMF Al 1.0101E+12. It is engineered to suit housing models AG 0030MF AG 0030 MF AG0030MF. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- AG 0030MF
- AG 0030 MF
- AG0030MF
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| XO | UF530XOYou are here | General Purpose Coalescer | 0.1 µm |
| A | UF530A | Activated Carbon | 0.01 µm |
| A | UF530A-HT | Activated Carbon | 0.01 µm |
| HC | UF530HC | Hopcalite | — |
| P | UF530P | General Purpose Coalescer | 5 µm |
| P | UF530P-HT | General Purpose Coalescer | 3 µm |
| X | UF530X | General Purpose Coalescer | 1 µm |
| X | UF530X-HT | General Purpose Coalescer | 1 µm |
| XO | UF530XO-HT | General Purpose Coalescer | 0.1 µm |
| Y | UF530Y | Oil Removal Coalescer | 0.01 µm |
| Y | UF530Y-HT | Oil Removal Coalescer | 0.01 µm |
Features
- Grade XO media rated at 0.1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the Ultrafilter 80 new Sheet original, fits the existing housing without modification
- Suits AG 0030MF and 2 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Ring main protection
- Spray and blow off applications
