Description
Within the Walker Alpha OLD + Sterile range, the WF0406Y is the Ultramax Systems replacement element. It is a Grade Y high efficiency oil removal coalescing element and strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. The element belongs directly downstream of a Grade X stage. This is the stage that decides how much oil reaches the point of use. The element is built to the original dimensions and needs no modification to the housing. It is the element used in A028XA housings. Australian stock holding keeps lead times short, at a working budget price relative to the OEM part.
This replacement filter element from Ultramax is a high-quality, Walker Filtration Alpha Series-compatible alternative. Designed as an alternative to OEM part numbers E0406XA EWK0406H OWAAE10406XA/S APW0406F EWK0406H-WAAE Walker Filtration E0406XA Walker Filter E0406XA. It is engineered to suit housing models A028XA. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference
- A028XA
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | WF0406YYou are here | Oil Removal Coalescer | 0.01 µm |
| A | WF0406A | Activated Carbon | 0.01 µm |
| P | WF0406P | General Purpose Coalescer | 5 µm |
| P | WF0406P25 | General Purpose Coalescer | 25 µm |
| X | WF0406X | General Purpose Coalescer | 1 µm |
| YO | WF0406YO | Oil Removal Coalescer | 0.1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Walker Alpha OLD + Sterile original, fits the existing housing without modification
- Suits A028XA housings
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Printing and packaging equipment
- Electronics assembly and test
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
