Description
The AOK 13 is an automatic mechanical condensate drain designed for fully automatic discharge from compressed air systems rated to 13 barg. Condensate accumulates in the nylon (PA) reservoir; when the level is sufficient, a precision float-controlled direct-acting valve opens and discharges up to 167 l/h at 7 bar without air loss. A manual drain on the front of the unit allows venting during commissioning or service. The AOK 13PA installs as an external drain on compressors, after-coolers, cyclone separators, air receivers, dryers and filter housings via 1/2" BSP connections, operating from 1.5 to 65 degrees C.
Features
- Float-controlled valve opens only when condensate is present - no air loss
- Drain capacity 167 l/h at 7 bar, rated to 13 barg
- Lightweight nylon (PA) body for standard industrial installations
- Front-mounted manual drain for venting and commissioning
- 1/2" BSP connections for standard compressed air fittings
- Operating temperature range 1.5 to 65 degrees C
Applications
- Piston and screw-type air compressors
- After-coolers and heat exchangers
- Cyclone condensate separators
- Compressed air receivers and pressure vessels
- Refrigeration and adsorption air dryers
- Compressed air filter housings
