Description
The AOK 50 is a high-pressure automatic mechanical condensate drain rated to 50 barg for heavy-duty compressed air applications. Condensate accumulates in the reservoir; a precision float-controlled direct-acting valve opens and discharges up to 145 l/h at 50 barg without air loss. A front-mounted manual drain provides venting during commissioning and maintenance. The AOK 50B features an aluminium body for standard industrial service; the AOK 50SS uses stainless steel 1.4408 for corrosive and hygienic environments. Both variants install via 1/2" BSP connections on compressors, separators and filter housings, operating from 1.5 to 65 degrees C.
Features
- Rated to 50 barg for heavy-duty high-pressure compressed air systems
- Float-controlled valve discharges only when condensate is present - no air loss
- Drain capacity 145 l/h at 50 barg
- Front-mounted manual drain for venting and commissioning
- Available in aluminium (AOK50B) or stainless steel 1.4408 (AOK50SS)
- 1/2" BSP connections, operating temperature range 1.5 to 65 degrees C
Applications
- High-pressure piston and screw compressors
- After-coolers on high-pressure systems
- Cyclone condensate separators in high-pressure service
- Compressed air receivers and pressure vessels rated to 50 bar
- Air filters and dryers in high-pressure installations
- Corrosive and hygienic compressed air environments (AOK50SS)
