Description
Within the Chicago Pneumatic New range, the CH45X is the Ultramax Systems replacement element. As a Grade X general purpose coalescing element it removes oil aerosol, water and solid particulate from the air stream, rated at 1 µm. The element belongs as the first coalescing stage, ahead of a dryer or a carbon tower. Removing the bulk of the liquid here is what lets the downstream element do its job. Dimensions follow the original, so it installs into the existing housing without modification. Housings in the G45 family take this element. Held in Australian stock, it is supplied at a working budget price rather than OEM list.
This replacement filter element from Ultramax is a high-quality, Chicago Pneumatic New-compatible alternative. Designed as an alternative to OEM part numbers 2258290112 | 8102852798 | 8102826271 | 8102852921 | 8102826404. It is engineered to suit housing models G45 | 1-S-G | 1S/G | 1SG | 1-G-G. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| Chicago Pneumatic New | 225829011281028527988102826271810285292181028264042258293101CPG25-45P1ECPG25UECPG45UOCP 45 G/XM1010100100502 |
|---|
- G45
- 1-S-G
- 1S/G
- 1SG
- 1-G-G
- 1-G-G 3/8
- 1G/G
- 1GG
- G25/45
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| X | CH45XYou are here | General Purpose Coalescer | 1 µm |
| Y | CH45A | Oil Removal Coalescer | 0.01 µm |
| P | CH45P | General Purpose Coalescer | 3 µm |
| Y | CH45Y | Oil Removal Coalescer | 0.01 µm |
Features
- Grade X media rated at 1 µm
- Removes oil aerosol, water and solid particulate from the air stream
- Dimensional match to the Chicago Pneumatic New original, fits the existing housing without modification
- Suits G45 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Compressed air ahead of a refrigerated or adsorption dryer
- Pneumatic tooling and cylinder control
- Compressor room outlet filtration
- Pre-filtration ahead of an activated carbon stage
