Description
Within the Chicago Pneumatic New range, the CH45Y is the Ultramax Systems replacement element. The element is a Grade Y high efficiency oil removal coalescing element, and strips the fine oil aerosol and water carryover a general purpose stage leaves behind, rated at 0.01 µm. It sits directly downstream of a Grade X stage. This is the stage that decides how much oil reaches the point of use. It matches the original on dimensional fit and drops into the existing housing without modification. It is the element used in C45 housings. Stock is held in Australia and supplied at a working budget price against going direct to the OEM.
This replacement filter element from Ultramax is a high-quality, Chicago Pneumatic New-compatible alternative. Designed as an alternative to OEM part numbers 2258290123 | 2258293201 | 8102853051 | 8102826537 | CPC25-45F. It is engineered to suit housing models C45 | 1-C-D | 1-D-G | 1C/D | 1CD. Manufactured to strict quality standards, it delivers reliable system protection at a competitive price.
Cross Reference Table
| Chicago Pneumatic New | 2258290123225829320181028530518102826537CPC25-45FECPG25HECPG45HOCP 45 C/XS1010100100503 |
|---|
- C45
- 1-C-D
- 1-D-G
- 1C/D
- 1CD
- 1-C-G
- 1-C-G 3/8
- 1C/G
- 1CG
- C25/45
Other Grades for This System
| Grade | Part number | Filtration | Micron |
|---|---|---|---|
| Y | CH45YYou are here | Oil Removal Coalescer | 0.01 µm |
| Y | CH45A | Oil Removal Coalescer | 0.01 µm |
| P | CH45P | General Purpose Coalescer | 3 µm |
| X | CH45X | General Purpose Coalescer | 1 µm |
Features
- Grade Y media rated at 0.01 µm
- Strips the fine oil aerosol and water carryover a general purpose stage leaves behind
- Dimensional match to the Chicago Pneumatic New original, fits the existing housing without modification
- Suits C45 and 4 further housing models
- Held in Australian stock, not brought in to order
Applications
- Paint and powder coating lines
- Instrument air and control circuits
- Air feeding pneumatic valves and actuators
- Processes sensitive to oil carryover
All brand names, trademarks and part numbers shown on this page remain the property of their respective owners and appear for identification purposes only. Ultramax Systems is not affiliated with, endorsed by, or a licensee of any manufacturer listed. Cross references indicate dimensional and performance equivalence, not original equipment supply. Please confirm the fitment against your housing before you order.
WarrantyEvery element is warranted to meet the Ultramax standard specification when it reaches you. If one does not, we will replace it, supply an equivalent, repair it, or cover the cost of replacing it. Tell us within 14 days of purchase to arrange a return. A restocking fee applies, and special order items cannot be returned. Our terms and conditions set out the detail.
