Description
The NUFORS-XF removes all types of condensate from large capacity compressed air applications up to 500 m3/min without using electricity and without unnecessary compressed air loss. It offers an exceptionally large condensate discharge capacity of 4800 litres per hour at 16 bar. The automatic discharge process uses a 3/2 way level controlled valve principle operating a piston type direct acting valve with a 12 mm orifice, allowing even heavily emulsified condensate to pass. Three 3/4 inch inlet options, a test feature and an optional mounting bracket simplify installation. The specially treated aluminium housing suits oil lubricated and oil-free systems and carries an IP68 (NEMA 6) enclosure protection rating.
Features
- Covers large compressed air systems up to 500 m3/min with one model
- No electricity required - install and go, no operating costs
- Zero compressed air loss during condensate discharge
- Large 12 mm valve orifice drains even heavily emulsified condensate
- Three inlet options plus test feature for routine checks
- IP68 (NEMA 6) rated corrosion resistant aluminium housing
Applications
- Condensate drainage on large receivers, aftercoolers and dryers
- Plants up to 500 m3/min compressor capacity
- Sites where power is unavailable, unreliable or expensive
- High condensate volume and heavily emulsified condensate duties
- Applications requiring a high enclosure protection rating
- Systems operating between 3 and 16 bar
