S/S Differential Pressure Gaug | SSDPG06F

Write a Review
SKU -
SSDPG06F
$951.50 Inc. GST
S/S Differential Pressure Gaug | SSDPG06F
$951.50 Inc. GST

Description

  • 65mm nominal ”square” dial size
  • ¼” BSP female in-line ports,
  • 316 Stainless Steel body
  • Buna N seals
  • Engineering Polymer case (with 4 screws)
  • Static pressure rating 6000 psi (420 bar)
  • Differential range 0/10 psi.

Specifications

Case Material
Polymer
Face Size (mm)
65mm Square or 115mm Round
Max Operating Pressure (bar)
200
Pressure Gauge Range
0-0.25 to 0-70 bar or equivalent range in other units
Porting
In-line, rear, bottom, in-line & bottom
Thread Type
¼” NPT(F) Std OR Optional ¼” BSP(F)
Max. Operating Temperature
80 ˚C
Seal Material
Buna-N
Seal Material
EPDM
Thread Size
1/4"
